An IP address is a unique address that is assigned to any device once connected to the internet to help identify it. There are two types of Ip addresses, Public and Private addresses. Public Addresses are routable on the world wide web and will grant you connectivity to other servers and routers around the world. Private addresses allow you to connect to an internal network example that of an organization, company, department, or Home network.
With a Linux distribution package like Ubuntu or Debian, you can configure network settings and configure interfaces to make them work according to your needs. The Linux kernel supports a variety of Network interfaces including lo for the local loopback interface, eth for ethernet card interface (eth0, eth1), tr for token ring card interface (tr0, tr1), and sl for SLIP interfaces (sl0, sl1).
You can assign a device a static IP address or use a Dynamic Host Control Protocol (DHCP). A server using the DHCP network protocol automatically assigns an IP address to a computer from a defined range of numbers configured for a given network. There are a set of graphical and command line utilities shipped with Ubuntu and Debian to configure Network settings. One of the is Netplan which we are going to look into in this guide.
What is Netplan?
Netplan is a network configuration abstraction renderer that is used to easily configure networking in a Linux system. It works by a system administrator creating a YAML file that constitutes the required network interfaces and what each should be configured to do. Then Netplan will generate all the necessary configurations for your chosen renderer tool. Netplan currently supports NetworkManager which would mean all interface configurations are handled by the GUI and Systemd-networkd renderer which allows the systems to handle all the network configurations.
You can create more than one configuration file with different configuration details. It is advisable to name them a numerical such as 01-config, 02-config, and so on. Netplan would parse the configurations from the files in numerical order where 01-config would be applied before 02-config
Install Netplan on Debian / Ubuntu
Before we can begin the installation, first update your system with the latest packages.
sudo apt update && sudo apt upgrade On the latest Ubuntu system (24.04), the Netplan utility is installed by default. For Debian System, install the Netplan utility with the following command
sudo apt install netplan.ioManage Ubuntu / Debian Networking using Netplan
Without a configuration file, Netplan would not do anything. We can create a simple file in the Netplan directory to bring things up via DHCP.
sudo nano /etc/netplan/config.yamlThen append the following lines noting the spaces as it is a Yaml file.
network:
version: 2
renderer: NetworkManagerSave and exit the file. This file makes the NetworkManager manage all devices.
To generate the required configuration for the renderers.
sudo netplan generateTo apply all configurations for the renderers, restart them as necessary.
sudo netplan applyTo apply configuration and wait for user confirmation;
$ sudo netplan try
Do you want to keep these settings?
Press ENTER before the timeout to accept the new configuration
Changes will revert in 112 seconds
Configuration accepted.To see your IP address
$ ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: ens18: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000
link/ether 6a:a8:04:c0:eb:0e brd ff:ff:ff:ff:ff:ff
altname enp0s18
inet 192.168.200.43/24 brd 192.168.200.255 scope global noprefixroute ens18
valid_lft forever preferred_lft forever
inet6 fe80::68a8:4ff:fec0:eb0e/64 scope link
valid_lft forever preferred_lft foreverTo view your default gateway, use the following command
$ ip r
default via 192.168.200.1 dev ens18 proto static metric 100
169.254.0.0/16 dev ens18 scope link metric 1000
192.168.200.0/24 dev ens18 proto kernel scope link src 192.168.200.43 metric 100 Dynamic IP Address Assignment using Netplan
To configure an interface to use DHCP, edit the configuration file and add the following lines by setting DHCP to true.
network:
version: 2
renderer: NetworkManager
ethernets:
ens18:
dhcp4: trueApply the configuration with the following command.
sudo netplan applyCheck your IP address to see the changes:
: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: ens18: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000
link/ether 6a:a8:04:c0:eb:0e brd ff:ff:ff:ff:ff:ff
altname enp0s18
inet 192.168.200.161/24 brd 192.168.200.255 scope global dynamic noprefixroute ens18
valid_lft 43197sec preferred_lft 43197sec
inet6 fe80::68a8:4ff:fec0:eb0e/64 scope link
valid_lft forever preferred_lft foreverStatic IP Address Assignment using Netplan
To set a static IP address with Netplan, edit the configuration file.
sudo nano /etc/netplan/config.yamlAdd the following lines and update the details with your preferred IP address, default gateway, and DNS server.
network:
version: 2
renderer: NetworkManager
ethernets:
ens18:
addresses:
- 192.168.200.49/24
nameservers:
search: [example.techview.com, sales.techview.com]
addresses: [8.8.8.8, 8.8.4.4, 192.168.200.1]
routes:
- to: default
via: 192.168.200.1Save and exit the file, then apply the changes by running the following command
sudo netplan applyConfirm your new static IP address.
$ ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: ens18: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel state UP group default qlen 1000
link/ether 6a:a8:04:c0:eb:0e brd ff:ff:ff:ff:ff:ff
altname enp0s18
inet 192.168.200.49/24 brd 192.168.200.255 scope global noprefixroute ens18
valid_lft forever preferred_lft forever
inet6 fe80::68a8:4ff:fec0:eb0e/64 scope link
valid_lft forever preferred_lft forever
Connecting Multiple interfaces with DHCP
Connecting to multiple networks through a specific interface with DHCP can be done as shown below.
network:
version: 2
ethernets:
enred:
dhcp4: yes
dhcp4-overrides:
route-metric: 100
engreen:
dhcp4: yes
dhcp4-overrides:
route-metric: 200Save and exit the file then apply the changes with the following command
sudo netplan applyConnect to an open Wireless network
To connect to a wireless network:
network:
version: 2
wifis:
wl0:
access-points:
opennetwork: {}
dhcp4: yesApply the changes:
sudo netplan applyConnect to a personal Network
This will involve providing the network name and password.
network:
version: 2
renderer: NetworkManager
wifis:
wlp2s0b1:
dhcp4: no
dhcp6: no
addresses: [192.168.0.21/24]
nameservers:
addresses: [192.168.0.1, 8.8.8.8]
access-points:
"network_ssid_name":
password: "**********"
routes:
- to: default
via: 192.168.0.1Apply the changes:
sudo netplan applyMultiple Addresses on a Single Interface
To connect to multiple interfaces on a single interface, assign a list of addresses to that interface as shown below.
network:
version: 2
renderer: NetworkManager
ethernets:
ens18:
addresses:
- 10.100.1.37/24
- 10.100.1.38/24:
label: enp3s0:0
- 10.100.1.39/24:
label: enp3s0:some-label
routes:
- to: default
via: 10.100.1.1Apply the changes
sudo netplan applyMultiple addresses with multiple gateways
To use multiple addresses with multiple gateways, the syntax is almost similar to the one above
network:
version: 2
renderer: NetworkManager
ethernets:
ens18:
addresses:
- 10.0.0.10/24
- 11.0.0.11/24
routes:
- to: default
via: 10.0.0.1
metric: 200
- to: default
via: 11.0.0.1
metric: 300Apply the changes:
sudo netplan applyConclusion
Netplan may be new and an alternate way to which most users were accustomed to configuring Linux network settings, but it is simple and easy to get used to. With just a simple configuration file written in YAML, Netplan parses the written configuration and applies it to the system. Should you have more than one interface and probably use two or more configuration files, Netplan applies the files in numerical order.
